CNC Stone Engraving Machine
Compact 3-axis CNC for granite, marble and artificial stone — 900×900 mm bed, 150 mm Z, 3 kW spindle to 24,000 RPM, NK-105 control with HPGL & G-code.
Minimum order 1 piece. Final price depends on options. GST invoice · quotation within 24 hours.
Shipping, returns & refunds per our Shipping Policy and Return & Refund Policy. 7-day return window for transit-damage claims; buyer bears return freight unless defect confirmed.
Compact CNC for precise stone engraving
Engraving is a cutting technique that carves a design into a hard surface to adorn or label objects. Traditionally done with manual tools, CNC engraving now uses computer-controlled milling paths created by CAD-CAM software from the design drawing.
Compared with manual engraving, CNC machines perform a wide range of advanced precision work for practical and artistic goals. The STX-0909 is a Success Technologies 3-axis stone engraving machine with a 900 × 900 mm bed — ideal for workshops that need accuracy on granite, marble and artificial stone without a full large-format footprint.
Features include well-selected mechanical and electrical design for a low breakdown rate, high-precision ball-screw transmission, a working table covered with rigid PVC sheet to protect the aluminium table, and imported square rails for accuracy under heavy workload.
| Model | STX-0909 |
|---|---|
| Brand | Success |
| Machine type | 3 Axis |
| X-Y axis working area | 900 × 900 mm |
| Z axis working area | 150 mm |
| Spindle power | 3 kW |
| Spindle head type | Single spindle |
| Spindle speed | 24,000 RPM |
| Cutting tool diameter | 1–12 mm |
| Command code | HPGL, G-code |
| Control system | NK-105 |
| Power consumption | 6 kW |
| Job material | Granite, marble, artificial stone, stone |
| Minimum order quantity | 1 Piece |
| Country of origin | Made in India |
900×900 mm bed
Compact X-Y working area suited to tiles, plaques and mid-size stone engraving jobs.
3 kW · 24,000 RPM
Single spindle with tool diameters from 1–12 mm for fine detail and heavier cuts.
Ball screw accuracy
High-precision ball-screw transmission for accurate engraving depth and path control.
Square rail · PVC table
Imported square rails for heavy workload; rigid PVC sheet protects the aluminium table.
NK-105 · HPGL / G-code
NK-105 control with HPGL and G-code for common CAD-CAM stone workflows.
Low breakdown design
Mechanical and electrical design with selected brand parts for workshop reliability.
Applications of the STX-0909
Precision engraving and carving on granite, marble, artificial stone and stone — for memorials, nameplates, tiles, reliefs and decorative stone products.
