Double Head CNC Stone Engraving Machine
High-clearance double-head 3-axis CNC for granite, marble, ceramic and sandstone — 1300×2500 mm bed, 400 mm Z, 4.5 kW spindle to 18,000 RPM, rack & pinion X-Y, ball-screw Z, 0.025 mm resolution.
Final price depends on options. GST invoice · quotation within 24 hours. Compare with our 200 mm Z STM-1325-2Z if you need a lower Z travel.
Shipping, returns & refunds per our Shipping Policy and Return & Refund Policy. 7-day return window for transit-damage claims; buyer bears return freight unless defect confirmed.
Double-head CNC with 400 mm Z clearance
Engraving is a cutting technique that carves a design into a hard surface to adorn or label objects. Traditionally done with manual tools, CNC engraving now uses computer-controlled milling paths created by CAD-CAM software from the design drawing.
Compared with manual engraving, CNC machines perform a wide range of advanced precision work for practical and artistic goals. This STM-1325-2Z configuration pairs a double head spindle with 400 mm Z travel and 4.5 kW spindle power — for thicker stone slabs and higher shop throughput on a 1300 × 2500 mm bed.
Application: 2D and 3D carving of fiberglass, stone, marble, sandstone, interior glazed wall tile, plastic, resin, black granite and EPP foam.
| Model | STM-1325-2Z |
|---|---|
| Brand | Success |
| Machine type | 3 Axis |
| X-Y axis working area | 1300 × 2500 mm |
| Z axis working area | 400 mm |
| Spindle power | 4.5 kW |
| Spindle head type | Double head spindle |
| Spindle speed | 18,000 RPM |
| X-Y movement | Rack & pinion |
| Z movement | Ball screw |
| Resolution | 0.025 mm |
| Command code | G-code |
| Driven motor | Stepper motor |
| Job material | Granite, ceramic, stone, marble, sandstone |
| Country of origin | Made in India |
Double head spindle
Two spindles for higher throughput on large stone engraving and carving jobs.
400 mm Z travel
Extra Z clearance for thicker slabs, deep relief and tall fixturing versus the 200 mm model.
1300×2500 mm bed
Full 4×8 ft X-Y working area for standard slab nesting without repositioning.
4.5 kW · 18,000 RPM
Spindle power and speed for granite, ceramic, marble and sandstone production work.
0.025 mm resolution
Rack & pinion X-Y, ball-screw Z, G-code and stepper drive for precise paths.
Ahmedabad support
Success-built with installation, training and spares from Odhav factory.
Applications of the STM-1325-2Z (400 mm)
2D and 3D carving of fiberglass, stone, marble, sandstone, interior glazed wall tile, plastic, resin, black granite and EPP foam — plus granite, ceramic and stone production engraving.
